| Size/Weight |
|---|
| Dimensions | Width |
1,326 mm [52-3/16"] |
|---|
| Height |
129 mm [5-1/16"] (with music rest: 327 mm [12-7/8"]) |
|---|
| Depth |
272 mm [10-11/16"] (with music rest: 362 mm [14-1/4"]) |
|---|
| Weight | Weight |
11.5 kg [25 lb, 6 oz] |
|---|
| Dimensions (with optional stand) | Width |
1,326 mm [52-3/16"] |
|---|
| Height |
744 mm [29-5/16"] (with music rest: 942 mm [37-1/16"]) |
|---|
| Depth |
318 mm [12-1/2"] (with music rest: 362 mm [14-1/4"]) |
|---|
| Dimensions of Packing Box | W x H x D |
1,424 mm x 362 mm x 233 mm [56-1/16" x 14-1/4" x 9-3/16"] |
|---|
| Control Interface |
|---|
| Keyboard | Number of Keys |
88 |
|---|
| Type |
GHC keyboard with matte black keytops |
|---|
| Touch Sensitivity |
Hard/Medium/Soft/Fixed |
|---|
| Panel | Language |
English |
|---|
| Voices |
|---|
| Tone Generator | Piano Sound |
Yamaha CFX |
|---|
| Key-off Samples |
Yes |
|---|
| Virtual Resonance Modeling (VRM) |
Yes (VRM Lite) |
|---|
| Damper Resonance |
- |
|---|
| Polyphony (max.) |
192 |
|---|
| Preset | Number of Voices |
24 |
|---|
| Effects |
|---|
| Types | Reverb |
4 types |
|---|
| Wall EQ |
Yes |
|---|
| Intelligent Acoustic Control (IAC) |
Yes |
|---|
| Stereophonic Optimizer |
Yes |
|---|
| Sound Boost |
2 types |
|---|
| Functions | Dual/Layers |
Yes |
|---|
| Split |
Yes |
|---|
| Duo |
Yes |
|---|
| Songs |
|---|
| Preset | Number of Preset Songs |
21 Voice Demo Songs + 50 Classics |
|---|
| MIDI Recording | Number of Songs |
1 |
|---|
| Number of Tracks |
2 |
|---|
| Data Capacity |
Approx. 100 KB/Song (approx. 11,000 notes) |
|---|
| Functions |
|---|
| Overall Controls | Metronome |
Yes |
|---|
| Tempo Range |
5 - 280 |
|---|
| Transpose |
-6 - 0 - + 6 |
|---|
| Tuning |
414.8 - 440.0 - 466.8 Hz (approx. 0.2 Hz increments) |
|---|
| USB Audio Interface |
44.1 kHz, 24 bit, stereo |
|---|
| Rhythm | Number of Rhythms |
20 |
|---|
| Bluetooth |
Audio (Varies by country) |
|---|
| Storage and Connectivity |
|---|
| Connectivity | Headphones |
Standard stereo phone jack (x 2) |
|---|
| AUX OUT |
[L/L+R] [R] |
|---|
| USB TO HOST |
Yes |
|---|
| DC IN |
12 V |
|---|
| Sustain Pedal |
Yes |
|---|
| Pedal Unit |
Yes |
|---|
| Amplifiers and Speakers |
|---|
| Amplifiers |
7 W x 2 |
|---|
| Speakers |
(Oval (12 cm x 8 cm) + 5 cm) x 2 |
|---|
| Power Supply |
|---|
| AC Adaptor |
PA-150B or an equivalent recommended by Yamaha (Output: DC 12 V, 1.5 A) |
|---|
| Power Consumption |
9 W (When using PA-150B AC adaptor) |
|---|
| Accessories |
|---|
| Included Accessories |
Owner’s Manual, Online Member Product Registration, Music rest, Footswitch, AC adaptor* (PA-150B or an equivalent recommended by Yamaha) *Varies by area |
|---|
| Separately Sold Accessories |
Headphones (HPH-150, HPH-100, HPH-50), Keyboard stand (L-200), Pedal unit (LP-1), Foot pedal (FC3A), Footswitch (FC4A, FC5), Keyboard bag (SC-KB851), AC adaptor* (PA-150B or an equivalent recommended by Yamaha), Wireless MIDI adaptor (UD-BT01) *Varies by area |
|---|
